So I wanted to backup an old DVD disc digitally in macOS Catalina, but to my surprise it was not mountable using Disk Utility – only showing the error:
Could not mount (com.apple.DiskManagement.disenter error 49153)
And by using the following Terminal.app command it did not work either, not giving more clues about the underlaying error unfortunately:
% diskutil mount disk3s1s2 Volume on disk3s1s2 failed to mount If you think the volume is supported but damaged, try the "readOnly" option
By inspecting the technical details of the disk lead me to a clue, that the old – in the meantime unsupported – Apple_HFS format may be the issue. A web search confirmed this assumption.
% diskutil list ... /dev/disk3 (external, physical): #: TYPE NAME SIZE IDENTIFIER 0: CD_partition_scheme *790.5 MB disk3 3: >>>> Apple_HFS <<<< 653.5 MB disk3s1s2
But for sure you can somehow teach macOS Catalina the ancient language of «HFS» – Apple’s own Hierarchical File System format – right?
And thanks to Unix: yes, you can!
Teaching macOS to read HFS volumes
Bringing back HFS support to macOS comes in 2 variations:
- HFS+ Plus – best case: a simple and well supported solution
HFS+ = Mac OS Extended - HFS – the “oh f*ck” case: a more complex, technical solution
HFS = Mac OS Standard or HFS Standard
Unfortunate for me, I had to go down the road of the 2nd approach.
But fortunate for you, because I can explain you here both approaches.
I definitely recommend to start with approach #1 if you can. Both solutions work alongside each other.
Prepare reading HFS formats in macOS: install Homebrew
For either of the following cases, you need to install Homebrew – the Missing Package Manager for macOS (and Linux).
- Open the
Terminal.appfrom Utilities folder (CMD+Ein Finder)
- Paste the following command & start it by pressing
RETURN
/bin/bash -c "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/HEAD/install.sh)"
Follow the instructions in the Terminal window until the installation on your system has finished successfully.
#1 – Best case scenario:
reading HFS Plus (HFS+) volume format
For this you will first need to install the FUSE application for macOS, accompanied with a separate FUSE driver framework.
First: Install FUSE for macOS
- Download & install FUSE for macOS from the official website: https://osxfuse.github.io
Then: Install the FUSE driver for HFS+
- Download the ZIP of hfsfuse from their official GitHub project page:
hfsfuse-master.zip - Unzip the
hfsfuse-master.zipZIP-file - Open to the Terminal.app (from
Applications»Utilities)& navigate into the unzippedhfsfuse-master-folder usingcd-command and the path where you unzipped the folder:cd ~/Downloads/hfsfuse-master
NOTE: if the unzipped folder is not in your user’s
/Downloads/-folder, then adjust the path accordingly! - Now install the «hfsfuse» driver using the following command in the Terminal:
make install
Now mount the HFS+ volume in Finder using hfsfuse
First create an empty folder in Finder, into which the HFS+ volume content will be mounted into later.
It doesn’t matter where you create this folder.
In Terminal.app use the following command to mount the HFS+ volume:
sudo hfsfuse --force -o noatime /dev/[DEVICE IDENTIFIER] /path/to/empty/folder
NOTE: you have to adjust /path/to/empty/folder, to the folder location you created before!
That’s it! (if no error is shown) You should be able to browse all contents in the mounted directory & get your files!
#2 – The “oh f*ck” case:
reading data in the original HFS format
This second approach is needed when you already know your Apple_HFS volume is actually of classic HFS – or you tried solution #1 and you got this error…
Plain HFS volumes not currently supported
Couldn't open volume: Undefined error: 0
You need the hfsutils tools for reading a classis Macintosh HFS volume.
Install the hfsutils tools
- Switch to the Terminal.app & install hfsutils using Homebrew
brew install hfsutils
Load and view the data on the HFS volume using hfsutils
With hfsutils things work differently – thus more technical/complex – than e.g. compared with hfsfuse. This means you will not get any UI to browse files & folders from the mounted HFS volume, but do all the work with the Terminal prompt. On top of that, you can only extract files, no whole directories or even files across multiple directory levels.
Let’s get started by first virtually mounting the HFS volume using:
sudo hmount /dev/disk3s1s2
Now you should already be able to browse the file hierarchy. For this use the hls command – listing all files & folders in the volume’s root level:
sudo hls
In order to browse subdirectories on the volume, use the hls command followed by the quoted directory path with prefixed : double-quotes:
NOTE: With hls you always have to use : double-quotes because they represent the directory structure – like ususally / slash in regular Unix file paths!
sudo hls ":Desktop Pictures"
soulblighter&832x624.jpg soulblighter@1024x768.jpg soulblighter@640x480.jpg
Copy data from the mounted HFS volume using hcopy
Once you got the hang how to browse and view files and folders, you may want to copy certain files from the volume. In order to do so, you can use the hcopy command – and fortunately *-wildcards for including multiple files are supported, however limited on a per folder basis.
Before you start, change the current working directory of the Terminal window into a Finder folder where you want to copy the files into. E.g.:
cd ~/Documents/My-HFS-Volume-Backup
And then use hcopy to transfer single or multiple files to the current working dir as follows:
sudo hcopy -r ":Desktop Pictures:soulblighter&832x624.jpg" ./
sudo hcopy -r ":Desktop Pictures:*" ./
NOTE: The -r option stands for “Raw Data” and based on my experience preserves the Macintosh files with the best possible success rate. Alternatively you can leave it away to use the “Automatic” mode (-a).
Once you are finished, you can disconnect the HFS volume with the following command:
humount
That’s it for scenario #2 – retrieving files from an unreadable classic HFS standard volume using macOS Catalina!
